Introduction
Manual pallet jacks cause back pain. Lead acid batteries need water refills, leak acid, and take hours to charge. Our lithium battery pallet truck . Read on to see how this truck keeps your operators safe, cuts long-term costs, and fits tight spaces like trailers, elevators, and containers.
Benefits of a Lithium Battery Pallet Truck
Charging Advantage：Lead acid needs 6–8 hours of dedicated charging. Our lithium battery pallet trucks support “opportunistic charging,” meaning you can charge your battery during breaks or between tasks without having to schedule dedicated downtime. Maintenance is zero. No water. No acid leaks.
Battery Options: 24V or 48V. Capacity Specifications: 20Ah, 30Ah, 40Ah, or 60Ah. Battery weight ranges from 6 kg to 13.2 kg (±5%). The 24V battery pack can be removed in just a few seconds. It can be operated with one hand, without the need for other tools. Our trucks can easily handle long shifts and will not be forced to stop working due to running out of battery.
No Hoses：This product features no hydraulic hoses. Most pallet truck malfunctions are caused by hose leaks. consequently, we have completely eliminated all hoses and lines from the hydraulic lifting circuit. There are absolutely no leaks at any connections or seals. All parts are within easy reach, and maintenance requires no special tools.
Strong Frame：The frame is stamped steel with a strong steel apron protecting all components. The fork has full length double sided C shape reinforcement. This increases strength and rigidity. The unique fork design also allows easy entry and exit from pallets.
Safety and Comfort
Ergonomic Tiller
Operators use this warehouse pallet truck for hours every day. The ergonomic smart tiller has soft grips for comfort. Buttons are large – easy to press even with thick work gloves.
Dual Butterfly Thumb Controls
The dual butterfly thumb controls put three functions within thumb reach: emergency reverse, horn, and electric lifting/lowering.
PIN Code and LCD Display
The PIN code panel with LCD display provides four functions. PIN start prevents unauthorized use. The battery discharge indicator shows remaining power. The operating hour counter tracks usage for maintenance planning. Error code diagnostics allow troubleshooting without external tools.
Turtle Speed Button
Press and hold the Turtle button. The truck runs with the handle in the upright position at reduced speed. This allows safe operation in tight spaces: trailers, containers, elevators, and mezzanines.
Emergency Reverse and Horn
Both emergency reverse and horn are on the thumb controls. The operator can react instantly when an obstacle or person appears.
Specs & Performance
Climbing performance:
Laden (with load): up to 4% incline
Unladen (without load): up to 16% incline
For 1000×1200 pallets with 1200 cross fork placement, the required aisle width is 1804mm. For 800×1200 pallets with 1200 along the fork, the required aisle width is 1854mm. This truck operates well in narrow aisles, elevators, trailers, and containers.
Key specifications from product data:
| Rated load capacity | 1500kg/2000kg |
| Load center | 600mm |
| Wheelbase | 1243mm |
| Self weight (excl. battery) | 142kg/146kg |
| Drive wheel size | φ210×70mm (PU) |
| Bearing wheel size | φ80×60mm (PU) |
| Number of wheels | 1x/4 |
| Ground clearance | 35mm |
| Noise level | ≤70dB |
| Drive motor power | 0.75 kW |
| Lifting motor power | 0.5 kW/0.8 kW |
| Drive control type | DC speed control |
| Steering type | Mechanical |
Best Use Cases
This electric pallet truck 2000 kg is specifically designed for warehousing and retail applications.
Distribution and Retail Operations:
Features low operating noise levels (≤70 dB), zero exhaust emissions, and is maintenance-free.
Warehouses with Elevators:
With a low curb weight (only 142–146 kg) combined with an exceptionally tight turning radius, it can easily enter and exit elevator cabs.
Trailers and Containers:
Equipped with a “tortoise mode” and compact dimensions, it allows for safe and risk-free maneuvering within trailers or shipping containers.
Mezzanines and Elevated Storage Areas:
Maintains a 4% gradeability even under full load, sufficient to handle most mezzanine ramps. The forks have a minimum height of just 85 mm, allowing them to easily slide beneath the vast majority of pallets.
Workshops with Frequent Operational Pauses:
Supports “opportunity charging” during work intervals, eliminating the need—typical of lead-acid batteries—to set aside a dedicated 8-hour block for recharging.
Lithium vs Manual vs Lead-Acid
Compared to Manual Pallet Jacks:
Using a manual pallet jack often leads to operator fatigue and back injuries, resulting in lower work efficiency; our lithium-powered pallet jacks, however, completely eliminate this physical strain.
Compared to Lead-Acid Pallet Jacks:
Lead-acid batteries require a dedicated charging time of 6 to 8 hours, as well as weekly replenishment of distilled water and acid cleanup. Furthermore, replacing the battery is both time-consuming and requires the use of tools. In contrast, our products require absolutely no maintenance, and the battery can be swapped out in mere seconds using just one hand.
Long-Term Cost Comparison:
While manual pallet jacks have a low initial purchase price, they incur high labor costs and carry a significant risk of workplace injuries. Lead-acid pallet jacks have a moderate initial cost but entail high battery maintenance expenses. Our lithium-powered pallet jacks, though having a slightly higher initial purchase price, significantly reduce labor costs and require virtually no maintenance.
FAQ
Q: How to obtain product samples?
A: We can provide prototypes. The sample fee is 1.5 times the ex-factory price, which can be deducted from the payment after placing the order. The customer bears the sample shipping cost, and the delivery cycle is 7-10 working days.
Q: What is the minimum order quantity (MOQ)?
A: The MOQ for standard models is 30 units. Discounts can be negotiated for bulk orders; excluding sample orders, please consult sales for details.
Q: What shipping methods are supported?
A: We can provide sea freight (FCL/LCL), air freight, and international express (DHL/UPS/FedEx). You can choose according to the order quantity and time requirements. We can assist in arranging logistics and providing customs clearance documents.
Conclusion
This Lithium Electric Pallet Truck allows your operators to experience an immediate and significant difference: no more back strain, a substantial increase in the number of pallets moved per hour, and—best of all—no more anxiety over battery life or concerns about acid leaks. If you are interested in this product, please feel free to contact us for a quote.
